Summit LS Max Pole Mount
Strength, elegance, and practicality converge in the LS Max Pole Mount! Designed to be mounted on a 3" track (Traxtech, Berts, Cisco, Tite-lok), Kayak T-Track, or directly to a deck mounting plate (LS Max Base Plate), this mount offers versatility for various boat configurations.
The LS Max Pole Mount features 360-degree rotation of both the vertical and horizontal tubes, allowing for easy and convenient stowing. Its smooth rotation with adjustable tension ensures your transducer remains pointed precisely where you want it at all times.
Available in two adjustable height models, 6-12" and 12-24", both models feature a sliding adjustable arm with up to 9" of reach to accommodate any boat's needs. Designed to fit any of our Summit GEN 2 SILVER poles or any other pole with a 1 1/8 (1.125) diameter, the mount includes 2 anodized aluminum pole clamps for height adjustment.
For permanent mounting, 8mm thumb screws are used for the base, allowing the use of standard 1/4-20" hardware to fit through the holes.
Kayak Mounting: Use standard 1/4-20 T-bolts through the threaded holes for the thumb screws, with a female thumb screw nut on the top side.
Removable Mounting Without Track: The Summit LS Max Base Plate provides a mounting plate with thumbscrews (sold separately).
Please use the drop-down menu to choose the length variation. "6-12"" means the mount will be as short as 6" and as tall as 12". "12-24"" means the pole mount will be as short as 12" and as tall as 24" from the bottom of the base plate to the bottom of the horizontal tube.
Note:
- Only one black anodized pole collar is provided. It gets installed onto the pole and rests on top of the clamp to allow for pole rotation.
- Pole sold separately (ONLY WORKS WITH CARBON FIBER POLE, GEN 2 SILVER POLE OR 1.125" POLES) Link to poles
- Watch Assembly Video Here
- Track sold separately
- NOT RECOMMENED FOR TROLLING
Why Summit
Built for portability. Backed by a 2-year warranty. Supported by real people who use this gear every day.
Don’t run half a setup
Pair your gear the right way the first time. Our mounts, poles, and shuttles are built to work together—so you’re not piecing things together on the water.
So far so good. I’ve only mounted everything but looking forward to trying it out. Fit and finish is legit!!
This seems much sturdier than the ram mount version. That one worked well but would get wobbly while underway at more than 2 mph. I unfortunately didn’t ask prior to purchase if this was for a 4.5” track or 6” and its for a 6” track. That could be listed on the page for this to help others. Overall this bracket seems very study and works well. It’s much easier to get out of the water than the ram mount version
Great mount. Easy to adjust and quick to remove when motoring to different spots.
I have been using this for about six trips so far. Very happy with the system. It works well for my setup. We moved the transducer from the trolling motor to this pole. Very happy with the results.
Outstanding mount
Very robust
I would highly recommend this mount and pole kit
Works great!
Everything I expected
We have it installed on our boat, and so far we are very happy with the product's quality and performance!
parim
Absolutely fell in love! Ill be ordering another very soon
Great product. It was the perfect solution to mount my LiveScope on my Lund Alaskan.
Awesome!! product, well built
I like the mount. The only issue was the tube that slides inside the out was mushroomed some.Had to sand the tube some for it to fit inside
Really good for the money, well made and very affordable
Everything seems good! Haven’t used much yet. Customer service was great, took care of shipping issues very promptly!!!
Sturdy and works well in river current.
Purchased for my Old Town Sportsman 120. Easy assembly and install. Took maybe 15 minutes if that. Have used it a couple times now and it is very sturdy with great adjustment features. Definitely would recommend. Thanks again.
Our shop sells them to many different customers and they all seam to really enjoy them. I personally have two of them on two different boats I have and really love them.
Works great. I use with the base plate to move my Livescope between my boat and kayak
Great product love it.Thank you very much
Can’t wait to use it
I like it. It’s very well built.
Excellent quality.
Warranty is great on these, only had to pay shipping!
Looks good works as it should
Thoughts of including a locking position pin may be a good idea.
Really wish I would have ordered this mint before the ram mount for it great
Easy to use, very versatile, and built like a tank. Highly recommend.
