20AH NMC Lithium ION Battery With Charger

Overview

The Summit Lithium 20Ah NMC Battery is built for lighter forward-facing sonar setups and portable ice electronics that need solid runtime without extra weight. This battery delivers stable 14.8V power, zero voltage sag, and dependable cold-weather performance in a compact footprint. Perfect for fishermen running smaller screens or minimal shuttle loads who want a lighter pack that still holds up during long days on the ice.

Lithium NMC batteries are the superior choice for portable electronics:

• NMC maintains higher voltage under load.
• NMC Performs better in cold climates, especially below 32°F.
• LiFePO₄ has reduced power output and charging restrictions in the cold.

Industry leading Battery Management Platform
     Core Features:

• Real-Time Performance Monitoring
• State of Charge (SOC) accuracy to 99.5%
• Individual cell voltage tracking (±0.01V)

     Multi-zone temperature profiling

• Advanced Protection Systems
• Instantaneous over/under voltage response
• Microsecond short-circuit interruption
• Multi-point thermal management

     Active Cell Balancing

• Continuous voltage synchronization
• Prevention of cell degradation during cycles
• Enhanced energy preservation

 Key Features:

• Cold-weather ready — holds voltage in freezing temps
• Stable 14.8V output for clean sonar returns
• Zero drop-outs even when the screen brightness is cranked
• Lightweight — only 2.98 lbs
• Designed for portable sonar shuttles
• NMC chemistry for high energy density
• Fast charging with included 6A charger
• SAE quick-connect harness included
• Safe, protected power with integrated BMS

Ideal For:

• Fits best inside the Summit Shuttle but is compatible with most popular brands. Summit Fishing, HD Innovations, ArcLab, Fin Gear, Fish Armor, Ice Master Fishing, TKI, BassKhang, Vexilar, etc.
• Smaller FFS bundles (7–9")
• Lightweight pack builds
• Anglers who move often and want to keep weight down
• Backup power for longer trips

Technical Specs:

• Model: 2004
• Voltage: 14.8V nominal
• Peak Voltage: 16.8V
• Capacity: 20Ah
• Chemistry: Lithium NMC
• Max Continuous Discharge: 15A
• Weight: 2.98 lbs
• Certification: UN38.3
• Dimensions: 5 7/8" x 2 1/2" x 3 5/8"
• Weight: 2.9 lbs

What’s Included:

• 20Ah Summit Lithium Battery
• 6A Fast Charger
• SAE Quick-Connect Harness

Safety Notes:

• Charge only with included charger
• Do not charge below 32°F
• Keep away from water or moisture
• Do not expose above 158°F
• Do not open, modify, or short-circuit
